Anping Chuangqian Wire Mesh Co., Ltd
$1≥200Square Meter
| betaling Type: | T/T,L/C,D/P,D/A,Paypal |
| Incoterm: | FOB,CFR,CIF,EXW,FCA,CPT,CIP,DDP,DDU,DAF,DES,Express Delivery |
| Min. orde: | 200 Square Meter |
| vervoer: | Ocean,Land,Air,Express,Others |
| Haven: | Tianjin ,Xingang,Shanghai |
Materiaal: Gegalvaniseerde ijzerdraad
Sollicitatie: Schutting gaas
| Verkoopeenheden | : | Square Meter |
| Pakkettype | : | pallet |
The file is encrypted. Please fill in the following information to continue accessing it
Veldhek Gemaakt van hoogwaardig koolstofstaal, wordt ook wel runderhek of grasland hek genoemd. Veldhekken kunnen worden onderverdeeld in vaste knoopveldhek en scharniergewrichtshekken. Met gegalvaniseerd oppervlak hebben ze een goed anti-corrosie-effect. Ze worden gekenmerkt door de hoge sterkte, gemakkelijke installatie en lange levensduur en veel gebruikt voor het schermen van verschillende dieren zoals vee, paard, schapen en herten. Bovendien kunnen ze ook worden gebruikt met prikkeldraad of kippengaas voor boerenhek, tuinschermen, weghekwerk, boshekken enzovoort.
|
Galvanized Kraal Network/Galvanized field fence |
|
|
Material |
High tensile galvanized steel wire High carbon Hot-dip galvanized wire Low carbon Hot-dip galvanized wire Low carbon Electric galvanized wire PVC coated wire |
|
Wire diameter |
1.5mm, 1.6mm, 1.7mm, 1.8mm, 2.0mm, 2.2mm, 2.5mm |
|
Top & Bottom wire diameter |
2.0mm, 2.2mm, 2.5mm, 2.7mm, 3.0mm, 3.5mm, 4.0mm |
|
Vertical spacing |
150mm/6 Inch, 300mm /12 Inch |
|
No. of Horizontal wire |
7 - 23 |
|
Height |
0.8m, 0.9m, 1.0m, 1.2m, 1.4m, 1.5m, etc. |
|
Length |
50m/165ft , 100m/330ft |
|
Roll diameter |
200mm - 270mm |
|
Zinc coating |
20g/m2-330g/m2 |
| Tenshion strength | 400-1300N |
|
No.
|
Item
|
Specification
|
The top
and bottom
wires
diameter
|
The
middle
wires
diameter
|
Roll
diameter
|
|
1.
|
7/150/813/50
|
102+114+127+140+152+178
|
2.5
|
2.0
|
280
|
|
2.
|
8/150/813/50
|
89(75)+89+102+114+127+140+152
|
2.5
|
2.0
|
280
|
|
3.
|
8/150/902/50
|
89+102+114+127+140+152+178
|
2.5
|
2.0
|
280
|
|
4.
|
8/150/1016/50
|
102+114+127+140+152+178+203
|
2.5
|
2.0
|
280
|
|
5.
|
8/150/1143/50
|
114+127+140+152+178+203+229
|
2.5
|
2.0
|
280
|
|
6.
|
9/150/991/50
|
89(75)+89+102+114+127+140+152+178
|
2.5
|
2.0
|
280
|
|
7.
|
9/150/1245/50
|
102+114+127+140+152+178+203+229
|
2.5
|
2.0
|
280
|
|
8.
|
10/150/1194/50
|
89(75)+89+102+114+127+140+152+178+203
|
2.5
|
2.0
|
280
|
|
9.
|
10/150/1334/50
|
89+102+114+127+140+152+178+203+229
|
2.5
|
2.0
|
280
|
|
10.
|
11/150/1422/50
|
89(75)+89+102+114+127+140+152+178+203+229
|
2.5
|
2.0
|
280
|
|
Note: we can also produce the mesh according to the customers special requirements.
|
|||||
|
Y Post
|
|
|
Market
|
Australia/New Zealand/ South America/Mid east
|
|
Surafce Treatment
|
Hot dipped galvanized/ Painting
|
|
Packing
|
10pcs/bundle, 200pcs/pallet
|
|
Size
|
1.58kg/m , 1.86kg/m , 1.90kg/m , 2.04kg/m
|
|
Popular Length
|
0.45m
|
0.60m
|
0.90m
|
1.35m
|
1.50m
|
1.65m
|
1.80m
|
2.10m
|
2.40m
|
|
Holes New Zealand type
|
|
|
|
7
|
7
|
7
|
8
|
|
|
|
South America Type
|
|
|
|
|
|
5
|
|
9
|
|
|
T post
|
||||
|
Market
|
Eruope and north America
|
|||
|
Surafce Treatment
|
Hot dipped galvanized/ Painting
|
|||
|
Packing
|
Eruope and north America
|
|||
|
Size
|
0.95pounds/foot, 1.25pounds/foot, 1.33pounds/foot ,1.5pounds/foot
|
|||
